Rooftop Tripod Mount

Product Classification

Part Number 1000-0010-0298

Product Type Rooftop Tripod Mount

General Specifications

Mounting Non-penetrating

Sled, Quantity 3 Sled

 Dimensions

Height up to 120 in [3048 mm]

Vertical Pipe Dia. 2.4in – 4.5 in [60 mm – 114 mm]

(not included)

Pipe Length up to 10’ [3048mm]

Sled Width 18 in [457 mm]

Sled Length 86.4 in [2194 mm]

Weight, Total 336 lb [152 kg]

 Material Specifications

Material Type Hot dip galvanized steel

 Mechanical Specifications

Wind Rating For details please contact sales@emiproducts.com
or call 800-453-0050.

Wind Rating Test Method TIA/EIA-222

Note

Not Included Rubber mats (provided separately, Vertical pipe (provided separately)

Download Drawing
