Retaining Wall Angled Assembly

Product Classification

Part Number 1010-0000-0196

Product Type Retaining Wall Angled Assembly

General Specifications

Application This complete assembly includes the retaining wall and its foundations, providing angled support to enhance structural stability and accommodate various site-specific requirements.

Dimensions

Height 100.375 in [2,549.5 mm]

Width 89.75 in [2,279.7 mm]

Length 25.5 in [647.7 mm]

Weight, Total 1,330 lb [603.3 kg]

Height above Grade 6 in [152.4 mm]

Material Specifications

Material Type / Grade hot dipped galvanized steel / A36

Mechanical Specifications

Wind Rating For details please contact sales@emiproducts.com or call 800-453-0050.

Mounting Helical foundation
