5 Level H-Frame (108″ x 60″)

Product Classification

Part Number 1010-0010-0188

Product Type 5 Level H-Frame

General Specifications

Application Equipment mounting frame

Dimensions

Width 108.375 in [2752.73 mm]

Height 60.875 in [27.61 mm]

Depth 8 in [203.2 mm]

Weight 216.60 lb [98.25 kg]

Material Specifications

Material Type Hot dip galvanized steel

Mechanical Specifications

No. of Levels 5

No. of Posts 3

Download Drawing
